DMCNC-1200

DMCNC-1200 (Aluminum Profile CNC Drilling Milling Machine)

Technical Parameter：

Power supply 380V/50Hz

Input power 3kw

Main axis rev 18000rpm

Air pressure 0.5~0.6MPa

X-axis speed 1200mm

Y-axis speed 300mm

Z-axis speed 280mm

Processing range 100×140mm

Handle type ER25×Ф8

Dimension 2200×1500×1950mm

Weight about 610kg

It is mainly used for processing of extra-wide aluminum profile, also can be used to process aluminum profile vertical end-face material -discharging.Adopt servo motor to drive reducer, implement saw blade rotating positioning at any angle between 45°and 90°.
