ALUMOURI ZKT 1000 Zinc Kattel

ALUMOURI ZKT 1000 Zinc Kattel

General discription

The barrel type zinc plating machine is a new patent product, with simple structure, strong practicability, greatly reduce the labor intensity. Zinc plate directly put into the barrel, it distinctive features with energy-saving and time-saving. Without any deal gates and complicate discharge of material. Adaptation range: rolling galvanize iron, copper, nickel, chromium, etc.,

the most suitable for barrel rolling plating washer, screws, nails, hinge, pins etc.. this machine is possible working for zinc, nickel, chrome, and brass plating metal products. this machine capacity is 150kgs/ hour. the thickness of layer can be controlled by the current adjust.

Machine parameter:

Model : 500A

Motor power : 1.1kw

rectifier power : 500A

Energy consumption : 3.5kw per hour

380v/50hz Output : 250kgs/hour (pins or nail)

Drum size: 1.5m(dia) x 0.65m(width)

Zinc tank size: 1.7m(L)x1.2m(W)x 1.5m(H)
